- Free Shipping USA (Exc. HI, AK, PR)
Compatible:
2007 - 2015 Cadillac Escalade/ESV/EXT (6.2L)
2006 - 2009 Cadillac XLR (4.4L/4.6L)
2009 - 2013 Chevy Avalanche (5.3L/6.0L)
2010 - 2015 Chevy Camaro SS (6.2L)
2011 - 2017 Chevy Caprice (3.6L/6.0L)
2005 - 2013 Chevy Corvette (6.0L/6.2L)
2009 - 2021 Chevy Suburban (5.3L/6.2L)
2009 - 2021 Chevy Tahoe (4.8L/5.3L/6.2L)
2008 - 2010 Pontiac G8 (6.0L)
2007 - 2009 Hummer H2 (6.2L)
2007 - 2021 GMC Sierra (2.7L/4.3L/4.8L/5.3L/6.0L/6.2L)
2007 - 2021 GMC Yukon (4.8L/5.3L/6.2L)
2007 - 2021 GMC Yukon XL (5.3L/6.0L/6.2L)
2007 - 2021 Chevy Silverado (2.7L/4.3L/4.8L/5.3L/6.0L/6.2L)
2014 - 2017 Chevy SS (6.2L)
2006 - 2009 Cadillac STS-V (4.4L)
This part is legal for sale or use on Emissions Controlled Vehicles, Uncontrolled (Non-Emissions Controlled) Vehicles, and Racing Use Only Vehicles because it does not affect vehicle emissions and is not covered by emissions regulations.
Features:
- Requires no silicone for simple installation
- Excellent torque retention to prevent possible leaks caused from loosened bolts
- Aluminum carrier provides un-matched gasket strength, fit and durability
- Silicone elastomer beading provides a positive seal under severe temperatures and conditions
- Rubber coated sealing binder adds a third layer of protection and aids in the gaskets ability to seal even with small imperfections of mating surfaces
Bolt Count | 18 |
---|---|
Bolt Hole Size | 0.310 inch |
Brand | Mr. Gasket |
Emission Code | 5 |
Material | Silicone-Rubber w/ Aluminum carrier |
Packaging | Individual |
Product Type | Transmission Pan Gaskets |
Thickness | .033 inch |
Transmission | 6L80E |
6L85E | |
Warranty | Limited 90 Day |
Part Number | 51G07MRG |
