Radium Engineering® 20-0434 (11+) Ford Coyote 5.0L Fuel Rail Plumbing Kit
Radium Engineering® 20-0434 (11+) Ford Coyote 5.0L Fuel Rail Plumbing Kit

20-0434

Radium Engineering® (11-23) Ford Coyote Fuel Rail Plumbing Kit

Regular price$289.95
/
Shipping calculated at checkout.
  • In stock, ready to ship
  • Question? Call us at (888) 257-1077 🏁
  • Free Shipping USA (Exc. HI, AK, PR)

Compatible: (5.0L)

2011 - 2021 Ford Mustang GT

2011 - 2021 Ford F-150



This kit is compatible with all vehicles that use the 5.0L Ford Coyote modular engine including the direct injected 2018+ Mustang GT, 2011-2017 Mustang GT, Ford Shelby GT350, Ford Falcon, Ford F-150, etc. It can be used with OEM returnless or aftermarket return fuel systems. It also fits the Ford Racing Boss 302 Manifold.


Manufactured with a large internal bore, the fuel rail can support all necessary engine power requirements. They are CNC machined from solid 6061 aluminum, black anodized, and laser etched for a high quality surface finish. Each rail has three 8AN ORB (3/4-16 female) threads and one 1/8" NPT female port. Like the OEM fuel rails, the injector bores are 14mm ID so factory injectors are permitted. Additionally, these rails have provisions for the factory injector retaining clips, as shown below.





This kit
 is compatible with all fuel types including popular alcohol mixtures such as E85.

NOTE: The parts below may be required for the specific vehicle if the 20-0434 Fuel Rail Plumbing Kit (described below) is NOT purchased.
For the 2018+ Mustang GT, Radium P/N: 14-0358 (shown below) is required to adapt the OEM direct injection pump feed hose.





For the 2018+ Mustang GT and the Shelby GT350, Radium P/N: 14-0359 (shown below) is required to adapt the OEM fuel sensor.





INCLUDED:

20-0433 Ford Coyote Fuel Rail Kit:
-Black Anodized Laser Etched Aluminum Fuel Rails (x2)




Install Guide





Warranty:
